LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 262
Element Type Description
MinDepth 64f Minimum depth.
MinWidth 64f Minimum width.
MaxWidth 64f Maximum width.
Region
ProfileRegion2d
Measurement region.
Measurements\X Groove tool
measurement
X measurement.
Measurements\Z Groove tool
measurement
Z measurement.
Measurements\Width Groove tool
measurement
Width measurement.
Measurements\Depth Groove tool
measurement
Depth measurement.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
SelectType 32s
Method of selecting a groove when multiple grooves are
found:
0 – Max depth
1 – Ordinal, from left
2 – Ordinal, from right
SelectIndex 32s Index when SelectType is set to 1 or 2.
Location
32s
Setting for groove location to return from:
Groove Tool Measurement
