Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 266
Element Type Description
MaxVoidWidth 64f Maximum void width.
SurfaceWidth 64f Surface width.
SurfaceOffset 64f Surface offset.
NominalRadius 64f Nominal radius.
EdgeAngle 64f Edge angle.
Region
ProfileRegion2d
Edge region.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Axis
32s
Measurement axis:
0 – Edge
1 – Surface
2 – Distance
Gap Measurement
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
Flush Measurement
