Gocator Device Files • Job Files • 257
Element Type Description
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
RegionEnabled Bool Whether or not to use region. If region is disabled, all
available data is used.
Region
ProfileRegion2d
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\GlobalX Bounding Box tool
measurement
GlobalX measurement
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Bounding Box Tool Measurement
