Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 271
Element Type Description
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
ZRotationEnabled Boolean Setting to enable/disable rotation of bounding box
RegionEnabled Boolean Setting to enable/disable region.
Region
Region3D
Measurement region.
Measurements\X Bounding Box tool
measurement
X measurement.
Measurements\Y Bounding Box tool
measurement
Y measurement.
Measurements\Z Bounding Box tool
measurement
Z measurement.
Measurements\Width Bounding Box tool
measurement
Width measurement.
Measurements\Height Bounding Box tool
measurement
Height measurement.
Measurements\ZAngle Bounding Box tool
measurement
ZAngle measurement.
Measurements\GlobalX Bounding Box tool
measurement
Global X measurement.
Measurements\GlobalY Bounding Box tool
measurement
Global Y measurement.
Measurements\GlobalZAngle Bounding Box tool
measurement
Global Z Angle measurement.
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
Bounding Box Tool Measurement
