LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 273
Element Type Description
RefRegionCount 32s Count of the reference regions which are to be used
RefRegions (Collection)
Reference regions. Contains 2 SurfaceRegion2D elements.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction:
0 – Disable
1 – Enable
TiltXAngle 64f Setting for manual tilt correction angle X.
TiltYAngle 64f Setting for manual tilt correction angle Y.
CurveFitEnabled Boolean
Setting to enable/disable curve fitting:
0 – Disable
1 – Enable
CurveOrientation 64f Setting for curve orientation angle.
Measurements\X Countersunk Hole tool
measurement
X measurement.
Measurements\Y Countersunk Hole tool
measurement
Y measurement.
Measurements\Z Countersunk Hole tool
measurement
Z measurement.
Measurements\OuterRadius Countersunk Hole tool
measurement
Outer Radius measurement.
Measurements\Depth Countersunk Hole tool
measurement
Depth measurement.
Measurements\BevelRadius Countersunk Hole tool
measurement
Bevel Radius measurement.
Measurements\BevelAngle Countersunk Hole tool
measurement
Bevel Angle measurement.
Measurements\XAngle Countersunk Hole tool
measurement
X Angle measurement.
Measurements\YAngle Countersunk Hole tool
measurement
Y Angle measurement.
Measurements\CounterboreDe
pth
Countersunk Hole tool
measurement
CounterboreDepth measurement.
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Countersunk Hole Tool Measurement
