LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Device Files • Job Files • 278
Element Type Description
1 – Enable
DepthLimit
64f
The depth limit relative to the surface. Data below this limit
is ignored.
RegionEnabled Boolean
Setting to enable/disable region:
0 – Disable
1 – Enable
Region
Region3D
Measurement region.
RefRegionsEnabled Boolean
Setting to enable/disable reference regions:
0 – Disable
1 – Enable
RefRegionCount 32s Count of the reference regions that are to be used.
RefRegions
(Collection) Reference regions. Contains two RefRegion elements of type
SurfaceRegion2D.
AutoTiltEnabled Boolean
Setting to enable/disable tilt correction:
0 – Disable
1 – Enable
TiltXAngle 64f Setting for manual tilt correction angle X.
TiltYAngle 64f Setting for manual tilt correction angle Y.
Measurements\X Opening tool
measurement
X measurement.
Measurements\Y Opening tool
measurement
Y measurement.
Measurements\Z Opening tool
measurement
Z measurement.
Measurements\Width Opening tool
measurement
Width measurement.
Measurements\Length Opening tool
measurement
Length measurement.
Measurements\Angle Opening tool
measurement
Angle measurement.
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
Opening Tool Measurement
