Starting the engine for driving / switching it off
4.1 Starting the engine from the driver's cab
Operating Instructions GMK5250L 3 302 633 en 4 - 17
27.09.2017
Instrument panel Several lamps must go out on the instrument panel when the engine is
running.
• Check that the lamps (1) and (2) go out.
If one or both lamps are lit, refer to the information in section
Immediately
after you start to move
; Ã p. 5 - 35.
Lamp (3) goes out only when the vehicle starts moving.
• Stop the engine immediately if the lamp (1) is lit. Pay attention to other
messages in the on-board computer display.
• Check that the lamp (1) goes out.
– If the lamp (1) is lit:
The
Driving menu shows a symbol.
– If the lamp (1) flashes:
The steering angle of the 4th and 5th The axle line relative to the 1st to
2nd axle lines.
• Steer using the steering wheel – the steering angle is automatically
offset, and the lamp (1) goes out.
s
When the symbol (2)
is displayed:
The oil supply for the steering is still being built
up. If the symbol has not yet gone out, contact
Manitowoc Crane Care
When the symbol (3)
is displayed:
Service mode on.
Briefly switch the ignition off and then on
again. If the symbol is still shown, contact
Manitowoc Crane Care.
When the symbol (4)
is displayed:
The 4th and 5th axle lines are brought into the
straight running position, as far as is possible,
and can no longer be steered.
It is possible to steer the 1st to 2nd axle lines.
Arrange for the error to be rectified.
