Driving
5.1 Before driving
5 - 2 3 302 633 en Operating Instructions GMK5250L
27.09.2017
4. On the outrigger
– All outrigger beams must be fully retracted and secured to prevent
extension;
à p. 11 - 42.
– The outrigger pads must be in the driving position;
à p. 11 - 51.
5. The spotlight must be pivoted downwards (if present);
à p. 10 - 127.
The lighting on the outrigger must be switched off;
à p. 3 - 70.
6. Anemometer, air traffic control light and camera system must be
removed:
à Anemometer and air traffic control light, p. 11 - 126,
à Camera on main boom, p. 11 - 137.
7. The camera at the hoists is retracted;
à Camera on the hoists, p. 11 - 139.
8. The lighting carriers on the superstructure are folded out;
à Folding the
lighting carrier in/out
, p. 11 - 130.
9. Slide in the handrails on the turntable, depending on the equipment
fitted;
à Railings on the turntable, p. 11 - 129.
