Driving
5.1 Before driving
5 - 20 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Display
If there is no malfunction, the
Tachograph
display now shows the basic display:
–Date (4) and time (5)
– Driver 1 time group (1.1)
– Driver 1 diagram sheet inserted (1.2)
– Total kilometres of the truck crane (3)
– Driver 2 time group (2.1)
– Driver 2 diagram sheet inserted (2.2)
Setting the time groups
Set the time group for driver 1 using the
button (1).
The set time group is shown by the symbol (1.1).
Set the time group for driver 2 using the
button (2).
The set time group is shown by the symbol (2.1).
