Malfunctions in driving mode
7.6 Fuses
Operating Instructions GMK5250L 3 302 633 en 7 - 39
27.09.2017
Group F2
Group F3
Group F4
s
Designation Amperage (A) Function
F2/1 15 UB1 IOL 32
F2/2 15 UB1 IOL 32
F2/3 15 UB2 IOL 32
F2/4 15 UB2 IOL 32
F2/5 15 UB1 IOL 33
F2/6 15 UB1 IOL 33
F2/7 15 UB2 IOL 33
F2/8 15 UB2 IOL 33
Designation Amperage (A) Function
F3/1 20 UB ESX 4
F3/2 2 UB ESX 4
F3/3 20 UB ESX 5
F3/4 2 UB ESX 5
F3/5 5 Air-conditioning system fan
F3/6 5 CCS control unit
F3/7 5 UE CCM 11
F3/8 5 UE IOL 32/33
Designation Amperage (A) Function
F4/1 15 ABS trailer
F4/2 10
Heating time switch
Rotating beacons
F4/3 5
Control module CCM 11
Vehicle height monitoring system
F4/4 5
Power supply
Air intake inhibitor
Reverse camera
F4/5 5
Power supply relay
Outrigger control units
F4/6 2 ESX 4 sensors
F4/7 2 ESX 5 sensors
F4/8 2 Power supply
