Malfunctions in driving mode
7.6 Fuses
7 - 40 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Group F6
Other fuses
Designation Amperage (A) Function
F6/1 10 Left low-beam headlight
F6/2 10 Right low-beam headlight
F6/3 2 XSM 08
F6/4 – Unassigned
F6/5 – Unassigned
F6/6 – Unassigned
F6/7 – Unassigned
F6/8 – Unassigned
Designation Amperage (A) Function
F1 15 ABS control unit
F2 10 Diagnostics
F3 15
Suspended operators seat, CAN BUS
power supply
F4 10
Loudspeaker system, power supply
for ESX3 control unit
F5 15 Steering air intake inhibitor
F6 10
Crane cab heating, engine electronic
system (ADM, SCR)
F7 20
Compressed air system emergency
operation, ESX 3 control unit
F8 25 Transmission retarder
F9 10 Mirror adjustment
F10 20 Trailer brake lights
F11 15 Superstructure drive monitoring
F12 20 Engine control unit, tachograph
F13 25 Drive control
