Operating elements for crane operation
8.2 Brief description of the operating elements
8 - 116 3 302 633 en Operating Instructions GMK5250L
27.09.2017
CCS display
Power units display
High-speed mode inspection derricking gear
Side panel
Raise enable button after RCL shutdown
RCL override – version A;
à p. 8 - 137.
RCL override – version B;
à p. 8 - 138.
–Green: Derricking gear on
–Red: Derricking gear off
–On: High-speed mode on
– Off: High-speed mode off
à p. 10 - 113
