Rigging work
11.5 Starting the engine for driving for rigging work
Operating Instructions GMK5250L 3 302 633 en 11 - 25
27.09.2017
11.5.2 Starting/switching off the engine from the outrigger control
units
Prerequisites The following requirements must be met before you can start the engine for
driving from the outrigger control units:
– The ignition in the driver's cab must be switched on.
– The ignition is switched off in the crane cab.
– The lamp in the button (1) lights up.
Start the engine All activities and checks required to start the engine must be carried out
before starting the engine;
à p. 4 - 1.
• Press the button (3) once – the engine will start.
Switching off
the engine
• Press the button (1) once – the engine will switch off.
