Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating Instructions GMK5250L 3 302 633 en 14 - 65
27.09.2017
s
Designation Amperage (A) Function
F2/1 15 Control unit UB 1 IOL 30
F2/2 15 Control unit UB 2 IOL 30
F2/3 15 Control unit UB 2 IOL 30
F2/4 15 Control unit UB 1 IOL 34
F2/5 15 Control unit UB 2 IOL 34
F2/6 15 Control unit UB 2 IOL 34
F2/7 15 Control unit UB 2 IOL 34
F2/8 – Unassigned
Designation Amperage (A) Function
F3/1 – Unassigned
F3/2 – Unassigned
F3/3 – Unassigned
F3/4 3 Crane cab lighting
F3/5 5 Display
F3/6 5 Hand-held control
F3/7 – Unassigned
F3/8 – Unassigned
