Malfunctions during crane operation
14.8 Fuses in the crane cab
14 - 66 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Designation Amperage (A) Function
F4/1 3
Control unit UE IOL 30
Control unit CCM 10
Control units IOS 20 and IOS 22
F4/2 – Unassigned
F4/3 3 CraneSTAR system
F4/4 10 Radio
F4/5 – Unassigned
F4/6 – Unassigned
F4/7 – Unassigned
F4/8 – Unassigned
Designation Amperage (A) Function
F5/1 3
Control unit CCM 10
Control units IOL 30 and IOS 22
Control unit SCM 15
F5/2 5 Control units 15 IOS 20 and 21
F5/3 3 Display
F5/4 3 Control lever supply
F5/5 5 Control lever supply
F5/6 – Unassigned
F5/7 – Unassigned
F5/8 5 Instrument lighting
