Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating Instructions GMK5250L 3 302 633 en 14 - 67
27.09.2017
Designation Amperage (A) Function
F6/1 10 Windscreen wiper/washing system
F6/2 15
Cigarette lighter
Socket 12 V
F6/3 10 Crane cab spotlight
F6/4 15
Main boom spotlight
Spotlight adjustment
F6/5 5 Houselock
F6/6 3 CraneSTAR system
F6/7 3 Remote control
F6/8 5 Camera system
Designation Amperage (A) Function
F7/1 3 Rotating beacons
F7/2 5 Diagnostics plug
F7/3 15 Heating control
F7/4 15 Extendable step
F7/5 3 Hoist camera tripod
F7/6 – Unassigned
F7/7 – Unassigned
F7/8 – Unassigned
Designation Amperage (A) Function
F8/1 3 VCC perm SCM
F8/2 3 VCC perm SCM 10
F8/3 3 VCC perm SCM IOL 30
F8/4 3 VCC perm SCM IOL 34
F8/5 – Unassigned
F8/6 – Unassigned
F8/7 – Unassigned
F8/8 3 AGND SCM
