Mitsubishi FX3U-232-BD User Manual

B-11
FX Series PLC User's Manual - Data Communication Edition
N:N Network
2 Specifications
2.2 Link Specifications
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
2.2.2 Link time
The link time indicates the cycle time in which link devices are updated.
The link time varies depending on the number of linked units (master station and slave stations) and the
number of linked devices as shown in the table below.
Unit: ms
Number of
linked
stations
Pattern 0 Pattern 1 Pattern 2
0 bit-devices
4 word-devices
32 bit-devices
4 word-devices
64 bit-devices
8 word-devices
218 22 34
326 32 50
433 42 66
541 52 83
649 62 99
757 72 115
865 82 131
