Mitsubishi FX3U-232-BD User Manual

A-32
FX Series PLC User's Manual - Data Communication Edition
Common Items
2 Communication Types and Communication Equipment
2.3 Combination of Communication Equipment (Block Diagram)
2.3.4 For FX1N Series
8-pin MINI-DIN,
female
FX 1N Series
A
C
B
One line can be selected.
N:N Network
Parallel link
Computer link
Non-protocol
communication
Programming
communication
Computer link
Non-protocol
communication
Programming
communication
Remote
maintenance
FX 0N -232ADP
A
FX 1N -232-BD
B
FX 1N -CNV-BD
B
FX 2NC -232ADP
A
9-pin D-Sub, male
25-pin
D-Sub,
female
9-pin D-Sub, male
RS-485
RS-232C
RS-422
Non-protocol
communication
FX 1N -422-BD
B
FX 1N -CNV-BD
B
FX 2NC -485ADP
A
FX 0N -485ADP
A
M3 terminal
block
European
terminal block
FX 2NC -485ADP
A
FX 0N -485ADP
A
FX 1N -485-BD
B
FX 1N -CNV-BD
B
European
terminal block
M3 terminal
block
European
terminal block
For special function units/blocks , refer to the next page.
C
, and indicate the mounting position.
A B C
(For the mounting procedure, refer to the respective communication equipment manual.)










