A-46
FX Series PLC User's Manual - Data Communication Edition
Common Items
2 Communication Types and Communication Equipment
2.3 Combination of Communication Equipment (Block Diagram)
2.3.11 For FX2(FX) and FX2C Series (reference)
FX
2
(FX),FX
2C
Series
One line can be selected.
Computer link
Computer link
Non-protocol
communication
RS-485
RS-232C
Parallel link
FX
2
-40AP
A
FX
2
-40AW
A
M3.5 terminal block
Connector for
optical fiber
FX-485ADP
A
M3.5 terminal block
FX-232ADP
A
25-pin D-Sub, female
Dedicated
Dedicated
Parallel link
A
indicate the mounting position.
A
(For the mounting procedure, refer to the respective communication equipment manual.)





To Next Page
