Common Items
4 Introduction of Manuals (Type, Reading Method and Acquisition Method)
4.2 Introduction of Related Manuals
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
4.2.4 Related options for communication
The table below specifies the manuals for products required to use the options above in the system
configuration.
For communication in accordance with RS-485(422)
FX
3U-485-BD
INSTALLATION MANUAL
JY997D13001 Included
Describes the contents of the RS-485 communication
special expansion board, FX
3U -485-BD hardware
including the specifications and installation procedure.
FX3U-485ADP
INSTALLATION MANUAL
JY997D13801 Included
Describes the contents of the RS-485 communication
special adapter, FX
3U -485-ADP hardware including
the specifications and installation procedure.
FX3U-485ADP-MB
INSTALLATION MANUAL
JY997D26301 Included
Handling procedures of the RS-485
communication special adapter.
For the MODBUS serial communication network,
refer to the FX
3U Series User’s Manual -
MODBUS Serial Communication Edition.
For N:N link, parallel link, computer link or non-
protocol communication by RS and RS2
instructions, refer to the FX Series User’s Manual
- Data Communication Edition.
FX
0N-485ADP
INSTALLATION MANUAL
JY992D53101 Included
Describes the contents of the RS-485 communication
special adapter, FX
0N -485-ADP hardware including
the specifications and installation procedure.
FX2NC-485ADP
INSTALLATION MANUAL
JY997D01201 Included
Describes the contents of the RS-485 communication
special adapter, FX
2NC -485-ADP hardware including
the specifications and installation procedure.
FX2N-485-BD
HARDWARE MANUAL
JY992D73401 Included
Describes the contents of the RS-485 communication
expansion board, FX
2N -485-BD including the
specifications and installation procedure.
FX1N-485-BD
USER'S GUIDE
JY992D84201 Included
Describes the contents of the RS-485 communication
expansion board, FX
1N -485-BD hardware including the
specifications and installation procedure.
For communication in accordance with USB
FX
3U-USB-BD
USER'S MANUAL
JY997D13501 Included
Describes the contents of the USB
communication expansion board, FX
3U-USB-BD
hardware including the specifications and
installation procedure.
Manual name Manual number
Included/separate
document
Contents
Connector conversion board
FX
3U-CNV-BD
INSTALLATION MANUAL
JY997D13601 Included
Describes the contents of the FX
3U-CNV-BD
special adapter connection board hardware
including the installation procedure.
FX
2N-CNV-BD JY992D63601 Included
Describes the contents of the FX
2N-CNV-BD
special adapter connection board hardware
including the installation procedure.
FX
1N-CNV-BD JY992D84701 Included
Describes the contents of the FX
1N-CNV-BD
special adapter connection board hardware
including the installation procedure.
RS-485/RS-232C converter for computer link communication
FX-485-PC-IF-SET
HARDWARE MANUAL
JY992D81801 Included
Describes the contents of the FX-485-PC-IF-SET
interface unit hardware including the
specifications and installation procedure.
Manual name Manual number
Included/separate
document
Contents
