FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
4 Wiring
4.2 Selecting Cables and Connection Devices
4.2.3 F700 and A700 Series (built-in RS-485 terminal)
1. In the case of 1-to-1 connection
Set the terminal resistor switch in the F700/A700 Series inverter to "100 Ω".
2. In the case of 1-to-N connection
Set the terminal resistor switch in the last F700/A700 Series inverter to "100 Ω".
Twisted pair cable
Built-in RS-485
terminal
Twisted pair cable
Twisted pair cable Twisted pair cable
Built-in
RS-485
terminal
Built-in
RS-485
terminal
Built-in
RS-485
terminal
