Mitsubishi FX3U-232-BD User Manual

I-13
FX Series PLC User's Manual - Data Communication Edition
Remote Maintenance
3 System Configuration and Selection
3.2 Setting Applicable FX PLC and Communication Equipment
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
3.2 Setting Applicable FX PLC and Communication Equipment
Select a communication equipment combination, and put a check mark in the "Check" column.
During selection, pay attention to the following:
- In the table below, only the outside dimensions and D-SUB connector shape are different between units
shown in "FX
2NC-232ADP/FX0N-232ADP". Select either one.
- Remote maintenance is not provided for the FX
0, FX0S, FX0N, FX1, FX2(FX) and FX2C Series.
FX Series Communication equipment (option)
Total extension
distance
Check
FX
1S
15 m
(49' 2")
15 m
(49' 2")
FX
1N
15 m
(49' 2")
15 m
(49' 2")
FX
2N
15 m
(49' 2")
15 m
(49' 2")
FX 1N -232-BD
(9-pin D-Sub)
FX 1N -CNV-BD
+
FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
FX 1N -CNV-BD
+
FX 1N -232-BD
(9-pin D-Sub)
FX 1N -CNV-BD
+
FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
FX 1N -CNV-BD
+
FX 2N -232-BD
(9-pin D-Sub)
FX 2N -CNV-BD FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
FX 2N -CNV-BD
+
+
