Mitsubishi FX3U-232-BD User Manual

A-36
FX Series PLC User's Manual - Data Communication Edition
Common Items
2 Communication Types and Communication Equipment
2.3 Combination of Communication Equipment (Block Diagram)
2.3.6 For FX2N Series
FX 2N Series
A
C
DB
One line can be selected.
N:N Network
Parallel link
Computer link
Non-protocol
communication
Inverter
communication
Programming
communication
Computer link
Non-protocol
communication
Programming
communication
Remote
maintenance
Short mail
sending
FX 0N -232ADP
A
FX 2N -232-BD
B
FX 2N -CNV-BD
B
FX 2NC -232ADP
A
9-pin D-Sub, male
25-pin
D-Sub,
female
9-pin D-Sub, male
RS-485
RS-232C
RS-422
Non-protocol
communication
FX 2N -422-BD
B
FX 2N -CNV-BD
B
FX 2NC -485ADP
A
FX 0N -485ADP
A
8-pin MINI-DIN,
female
M3 terminal
block
European
terminal block
European
terminal block
M3 terminal
block
European
terminal block
FX 2N -485-BD
B
FX 0N -485ADP
A
FX 2NC -485ADP
A
FX 2N -CNV-BD
B
FX 2N -ROM-E1
D
Essential when inverter
communication is used.
FX 2N -ROM-E1
D
Essential when the short mail
sending is used
For special function units/blocks , refer to the next page.
C
, , and indicate the mounting position.
(For the mounting procedure, refer to the respective communication equipment manual.)
A
B C D












