Mitsubishi FX3U-232-BD User Manual

A-44
FX Series PLC User's Manual - Data Communication Edition
Common Items
2 Communication Types and Communication Equipment
2.3 Combination of Communication Equipment (Block Diagram)
2.3.10 For FX3UC-32MT-LT
FX 3UC -32MT-LT
C
B
A
N:N Network
Parallel link
Computer link
Non-protocol
communication
Inverter
communication
Programming
communication
Computer link
Non-protocol
communication
Programming
communication
Remote
maintenance
RS-485
RS-
232C
RS-422
FX 3U -485-BD
B
FX 3U -422-BD
B
8-pin MINI-DIN,
female
FX 3U -232-BD
B
9-pin D-Sub,
male
ch1
FX 3U -CNV-BD
B
FX 3U -485ADP
(-MB)
A
ch1
FX 3U -485ADP
(-MB)
A
ch2
European
terminal block
European
terminal block
European
terminal block
ch1
FX 3U -CNV-BD
B
FX 3U -485ADP
(-MB)
A
ch1
FX 3U -485ADP
(-MB)
A
ch2
European
terminal block
European
terminal block
Non-protocol
communication
FX 3U -CNV-BD
B
FX 3U -232ADP
(-MB)
A
ch1
FX 3U -232ADP
(-MB)
A
ch2
9-pin D-Sub,
male
9-pin D-Sub,
male
ch1
Programming
communication
USB
FX 3U -USB-BD
B
MINI-USB B plug,
female
ch1
Either FX 3U -
232ADP(-MB) or
FX
3U -485ADP(-MB)
can be selected.
For special function units/blocks , refer to the next page.
C
, and indicate the mounting position.
A B C
(For the mounting procedure, refer to the respective communication equipment manual.)
RD
RD A
RD B
SD A
SD B
SG
SD
RD
SD
RD
SD












