E-87
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
9 Creating Programs (for FX3U and FX3UC PLCs)
9.9 Second Parameter Specification Codes
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
9.9.7 A700 Series
1. Second parameter specification codes for parameter numbers 125, 126, C2 to C7, C12 to
C19, and C38 to C41
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in
IVRD/IVWR instruction for parameter number]
C2 Terminal 2 frequency setting bias frequency 902
C3 Terminal 2 frequency setting bias 1902
125 Terminal 2 frequency setting gain frequency 903
C4 Terminal 2 frequency setting gain 1903
C5 Terminal 4 frequency setting bias frequency 904
C6 Terminal 4 frequency setting bias 1904
126 Terminal 4 frequency setting gain frequency 905
C7 Terminal 4 frequency setting gain 1905
C12 Bias frequency (speed) for terminal No. 1 917
C13 Bias (speed) for terminal No. 1 1917
C14 Gain frequency (speed) for terminal No. 1 918
C15 Gain (speed) for terminal No. 1 1918
C16 Bias command (torque) for terminal No. 1 919
C17 Bias (torque) for terminal No. 1 1919
C18 Gain command (torque) for terminal No. 1 920
C19 Gain (torque) for terminal No. 1 1920
C38 Bias command (torque) for terminal No. 4 932
C39 Bias (torque) for terminal No. 4 1932
C40 Gain command (torque) for terminal No. 4 933
C41 Gain (torque) for terminal No. 4 1933
