12.4.9 Communication format setting [D8400 and D8420]
These devices set the communication format.
1. Detailed contents
These devices can set the data length, parity, baud rate, etc.
When communication port ch1 is used, D8400 sets the communication format.
When communication port ch2 is used, D8420 sets the communication format.
The table below shows the contents of the communication format settings. Computer link setting is not
applicable for D8400.
*1. Make sure to set as "0" when using computer link.
*2. Make sure to set as "0" when using non-protocol communication.
*3. In RS2 instruction, up to four headers and up to four terminators can be set.
*4. When executing non-protocol communication using RS2 instruction, add the sum check after the
terminators.
Make sure to set the terminators when adding the sum check.
2. Cautions on use
In FX3U and FX3UC PLCs, the communication format can be set using parameters.
Bit No. Name
Contents
0 (bit = OFF) 1 (bit = ON)
b0 Data length 7-bit 8-bit
b1
b2
Parity
b2, b1
(0, 0): Not provided
(0, 1): Odd
(1, 1): Even
b3 Stop bit 1-bit 2-bit
b4
b5
b6
b7
Baud rate
(bps)
b7, b6, b5, b4 b7, b6, b5, b4
(0, 0, 1, 1): 300 (0, 1, 1, 1): 4800
(0, 1, 0, 0): 600 (1, 0, 0, 0): 9600
(0, 1, 0, 1): 1200 (1, 0, 0, 1): 19200
(0, 1, 1, 0): 2400
b8
*1
Header Not provided
Provided
*3
b9
*1
Terminator Not provided
Provided
*3
b10
b11
b12
Control line
Non-protocol
communica-
tion
b12, b11, b10
(0, 0, 0):Not provided <RS-232C interface>
(0, 0, 1):Standard mode <RS-232C interface>
(0, 1, 0):Interlink mode <RS-232C interface>
(0, 1, 1):Modem mode <RS-232C interface>
(1, 1, 1):Communication in accordance with RS-485
<RS-485/RS-422 interface>
Computer link
b12, b11, b10
(0, 0, 0): RS-485/RS-422 interface
(0, 1, 0):RS-232C interface
b13 Sum check Not added
Added
*4
b14
*2
Protocol Not used Used
b15
Control proce-
dure (CR, LF)
Non-protocol
communica-
tion
CR, LF: Not used
(Format 1)
Non-protocol
communica-
tion
CR, LF: Used
(Format 2)
Computer link
CR, LF: Not used
(Format 1)
Computer link
CR, LF: Used
(Format 4)
