E-80
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
9 Creating Programs (for FX3U and FX3UC PLCs)
9.5 Inverter Operation Control Instruction (PLC → Inverter) [FNC271 / IVDR]
9.5 Inverter Operation Control Instruction (PLC→Inverter) [FNC271 / IVDR]
This instruction writes a control value required to operate an inverter from the PLC to the inverter.
9.5.1 Function and operation
When an "instruction code" specified for computer link operation in the inverters is specified in the IVDR
(FNC271) instruction, the value specified in is written to the specified item of the inverter.
1. Applicable devices
2. Program example
9.5.2 Inverter instruction codes
The table below shows inverter instruction codes which can be specified in .
For the instruction codes, refer to the pages explaining computer link in detail in each inverter manual.
*1. The instruction code "HFD (inverter reset)" does not request a response from the inverter.
Accordingly, even if inverter reset is executed to a station number at which an inverter is not
connected, error does not occur.
It takes about 2.2 seconds to complete execution of inverter reset.
*2. When resetting the inverter, please specify H9696 as the operand of the IVDR instruction.
Do not use H9966.
Oper-
and
Type
Bit Devices Word Devices Others
System/User Digit Specification System/User
Special
Unit
Index
Con-
stant
Real
Number
Charac-
ter String
Pointer
XYMTCSD
 .b KnX KnY KnM KnS T C D R U\G VZModifyKH E "  "P
   
   
   
n 
Inverter Instruction
code (hexadecimal)
Write contents
Applicable inverter
F700 A700 E700 V500 F500 A500 E500 S500
HFB Operation mode 
HF3 Special monitor selection No. ——
HF9 Run command (extension) —————
HFA Run command 
HEE Set frequency write (EEPROM) 
HED Set frequency write (RAM) 
HFD
*1
Inverter reset
*2

HF4 Alarm definition batch clear — 
HFC Parameter all clear 
HFC User clear — ——
S 3
S 1
S 2
S 3
M0
FNC271
IVDR
K6 HFA K2M50
S 1  S 2  S 3 
Command
contact
Inverter station number: 0 to 31
Inverter instruction code (hexadecimal)
Value written to inverter
K1
n
Communication channel K1:ch1
K2:ch2
S 2
S 2
S 3
