Inverter Communication
12 Related Data
12.5 FREQROL Inverter Parameter List
12.5.2 Parameters in F700, A700, and E700 Series
The following parameters are provided in the F700, A700, and E700 Series inverters. (For details, make sure
to refer to the respective inverter manual.)
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
Function
Pr
No.
Name Pr No. Name
Pr
No.
Name
Basic
functions
0 Torque boost 0 Torque boost 0 Torque boost
1 Maximum frequency 1 Maximum frequency 1 Maximum frequency
2 Minimum frequency 2 Minimum frequency 2 Minimum frequency
3 Base frequency 3 Base frequency 3 Base frequency
4Multi−speed setting (high speed) 4 Multi-speed setting (high speed) 4 Multi-speed setting (high speed)
5
Multi−speed setting
(middle speed)
5
Multi-speed setting
(middle speed)
5
Multi-speed setting
(middle speed)
6Multi−speed setting (low speed) 6 Multi-speed setting (low speed) 6 Multi-speed setting (low speed)
7 Acceleration time 7 Acceleration time 7 Acceleration time
8 Deceleration time 8 Deceleration time 8 Deceleration time
9 Electronic thermal O/L relay 9 Electronic thermal O/L relay 9 Electronic thermal O/L relay
DC injection
brake
10
DC injection brake operation
frequency
10
DC injection brake operation
frequency
10
DC injection brake operation
frequency
11
DC injection brake operation
time
11
DC injection brake operation
time
11
DC injection brake operation
time
12
DC injection brake operation
voltage
12
DC injection brake operation
voltage
12
DC injection brake operation
voltage
− 13 Starting frequency 13 Starting frequency 13 Starting frequency
− 14 Load pattern selection 14 Load pattern selection 14 Load pattern selection
Jog operation
15 Jog frequency 15 Jog frequency 15 Jog frequency
16
Jog acceleration/deceleration
time
16
Jog acceleration/deceleration
time
16
Jog acceleration/deceleration
time
− 17 MRS input selection 17 MRS input selection 17 MRS input selection
− 18 High speed maximum frequency 18 High speed maximum frequency 18 High speed maximum frequency
− 19 Base frequency voltage 19 Base frequency voltage 19 Base frequency voltage
Acceleration/
deceleration
times
20
Acceleration/deceleration
reference frequency
20
Acceleration/deceleration
reference frequency
20
Acceleration/deceleration
reference frequency
21
Acceleration/deceleration time
increments
21
Acceleration/deceleration time
increments
21
Acceleration/deceleration time
increments
Stall
prevention
22 Stall prevention operation level 22
Stall prevention operation level
(torque limit level )
22 Stall prevention operation level
23
Stall prevention operation level
compensation factor at double
speed
23
Stall prevention operation level
compensation factor at double
speed
23
Stall prevention operation level
compensation factor at double
speed
Multi−speed
setting
24 Multi-speed setting (speed 4) 24 Multi-speed setting (speed 4) 24 Multi-speed setting (speed 4)
25 Multi-speed setting (speed 5) 25 Multi-speed setting (speed 5) 25 Multi-speed setting (speed 5)
26 Multi-speed setting (speed 6) 26 Multi-speed setting (speed 6) 26 Multi-speed setting (speed 6)
27 Multi-speed setting (speed 7) 27 Multi-speed setting (speed 7) 27 Multi-speed setting (speed 7)
− 28
Multi-speed input compensation
selection
28
Multi-speed input compensation
selection
−−
− 29
Acceleration/deceleration pattern
selection
29
Acceleration/deceleration pattern
selection
29
Acceleration/deceleration pattern
selection
− 30 Regenerative function selection 30 Regenerative function selection 30 Regenerative function selection
Frequency
jump
31 Frequency jump 1A 31 Frequency jump 1A 31 Frequency jump 1A
32 Frequency jump 1B 32 Frequency jump 1B 32 Frequency jump 1B
33 Frequency jump 2A 33 Frequency jump 2A 33 Frequency jump 2A
34 Frequency jump 2B 34 Frequency jump 2B 34 Frequency jump 2B
35 Frequency jump 3A 35 Frequency jump 3A 35 Frequency jump 3A
