Mitsubishi FX3U-232-BD User Manual

E-135
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
12 Related Data
12.5 FREQROL Inverter Parameter List
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
Frequency
jump
36 Frequency jump 3B 36 Frequency jump 3B 36 Frequency jump 3B
− 37 Speed display 37 Speed display 37 Speed display
−−−−−40
RUN key rotation direction
selection
Frequency
detection
41 Up−to−frequency sensitivity 41 Up-to-frequency sensitivity 41 Up-to-frequency sensitivity
42 Output frequency detection 42 Output frequency detection 42 Output frequency detection
43
Output frequency detection for
reverse rotation
43
Output frequency detection for
reverse rotation
43
Output frequency detection for
reverse rotation
Second
functions
44
Second acceleration/
deceleration time
44
Second acceleration/
deceleration time
44
Second acceleration/
deceleration time
45 Second deceleration time 45 Second deceleration time 45 Second deceleration time
46 Second torque boost 46 Second torque boost 46 Second torque boost
47 Second V/F (base frequency) 47 Second V/F (base frequency) 47 Second V/F (base frequency)
48
Second stall prevention
operation current
48
Second stall prevention
operation current
48
Second stall prevention
operation current
49
Second stall prevention
operation frequency
49
Second stall prevention
operation frequency
−−
50
Second output frequency
detection
50
Second output frequency
detection
51
Second electronic thermal O/L
relay
51
Second electronic thermal O/L
relay
51
Second electronic thermal O/L
relay
Monitor
functions
52
DU/PU main display data
selection
52
DU/PU main display data
selection
52
DU/PU main display data
selection
54 FM terminal function selection 54 FM terminal function selection 54 FM terminal function selection
55 Frequency monitoring reference 55 Frequency monitoring reference 55 Frequency monitoring reference
56 Current monitoring reference 56 Current monitoring reference 56 Current monitoring reference
Automatic
restart
functions
57 Restart coasting time 57 Restart coasting time 57 Restart coasting time
58 Restart cushion time 58 Restart cushion time 58 Restart cushion time
− 59 Remote function selection 59 Remote function selection 59 Remote function selection
− 60 Energy saving control selection 60 Energy saving control selection 60 Energy saving control selection
Automatic
acceleration
/deceleration
−−
61 Reference current 61 Reference current
62 Reference value at acceleration 62 Reference value at acceleration
63 Reference value at dcceleration 63 Reference value at deceleration
64
Starting frequency for elevator
mode
−−
− 65 Retry selection 65 Retry selection 65 Retry selection
− 66
Stall prevention operation
reduction starting frequency
66
Stall prevention operation
reduction starting frequency
66
Stall prevention operation
reduction starting frequency
Retry
67
Number of retries at alarm
occurrence
67
Number of retries at alarm
occurrence
67
Number of retries at fault
occurrence
68 Retry waiting time 68 Retry waiting time 68 Retry waiting time
69 Retry count display erase 69 Retry count display erase 69 Retry count display erase
− 70 Special regenerative brake duty 70 Special regenerative brake duty 70 Special regenerative brake duty
− 71 Applied motor 71 Applied motor 71 Applied motor
− 72 PWM frequency selection 72 PWM frequency selection 72 PWM frequency selection
− 73 Analog input selection 73 Analog input selection 73 Analog input selection
− 74 Input filter time constant 74 Input filter time constant 74 Input filter time constant
− 75
Reset selection/disconnected PU
detection/PU stop selection
75
Reset selection/disconnected PU
detection/PU stop selection
75
Reset selection/disconnected PU
detection/PU stop selection
− 76 Alarm code output selection 76 Alarm code output selection −−
− 77 Parameter write selection 77 Parameter write selection 77 Parameter write selection
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
Function
Pr
No.
Name Pr No. Name
Pr
No.
Name
