FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
12 Related Data
12.5 FREQROL Inverter Parameter List
− 78
Reverse rotation prevention
selection
78
Reverse rotation prevention
selection
78
Reverse rotation prevention
selection
− 79 Operation mode selection 79 Operation mode selection 79 Operation mode selection
Simple
magnetic
flux vector
control
80
Motor capacity (simple magnetic
flux vector control)
80 Motor capacity 80 Motor capacity
−−
81 Number of motor poles 81 Number of motor poles
82 Motor excitation current 82 Motor excitation current
83 Motor rated voltage 83 Motor rated voltage
84 Rated motor frequency 84 Rated motor frequency
89
Speed control gain (magnetic
flux vector)
89
Speed control gain
(advanced magnetic flux vector)
90 Motor constant (R1) 90 Motor constant (R1) 90 Motor constant (R1)
−− −
91 Motor constant (R2) 91 Motor constant (R2)
92 Motor constant (L1) 92 Motor constant (L1)
93 Motor constant (L2) 93 Motor constant (L2)
94 Motor constant (X) 94 Motor constant (X)
95 Online auto tuning selection −−
96 Auto tuning setting/status 96 Auto tuning setting/status
Adjustable 5
points V/F
100 V/F1 (first frequency) 100 V/F1(first frequency)
−−
101 V/F1 (first frequency voltage) 101 V/F1(first frequency voltage)
102 V/F2 (second frequency) 102 V/F2(second frequency)
103 V/F1 (first frequency) 103 V/F2(second frequency voltage)
104 V/F3 (third frequency) 104 V/F3(third frequency)
105 V/F3 (third frequency voltage) 105 V/F3(third frequency voltage)
106 V/F4 (fourth frequency) 106 V/F4(fourth frequency)
107 V/F4 (fourth frequency voltage) 107 V/F4(fourth frequency voltage)
108 V/F5 (fifth frequency) 108 V/F5(fifth frequency)
109 V/F5 (fifth frequency voltage) 109 V/F5(fifth frequency voltage)
Third
functions
−−
110
Third acceleration/deceleration
time
111 Third deceleration time
112 Third torque boost
113 Third V/F (base frequency)
114
Third stall prevention operation
current
115
Thrid stall prevention operation
frequency
116 Third output frequency detection
PU connector
communica-
tion
117 PU communication station 117
PU communication station
number
117
PU communication station
number
118 PU communication speed 118 PU communication speed 118 PU communication speed
119
PU communication stop bit
length.
119
PU communication stop bit
length
119
PU communication stop bit
length
120 PU communication parity check 120 PU communication parity check 120 PU communication parity check
121
Number of PU communication
retries
121
Number of PU communication
retries
121
Number of PU communication
retries
122
PU communication check time
interval
122
PU communication check time
interval
122
PU communication check time
interval
123
PU communication waiting time
setting
123
PU communication waiting time
setting
123
PU communication waiting time
setting
PU connector
communicati
on
124
PU communication CR/LF
presence/absence selection
124
PU communication CR/LF
presence/absence selection
124
PU communication CR/LF
selection
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
Function
Pr
No.
Name Pr No. Name
Pr
No.
Name
