FX Series PLC User's Manual - Data Communication Edition
Parallel Link
10 Related Data
10.2 Details of Related Devices
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
10.2.9 Serial communication error code [D8063 and D8438]
These devices store the serial communication error code. (D8438 is available only in the FX3U and FX3UC.)
1. Applicable stations
The master and slave station may check the serial communication error code.
2. Detailed contents
The table below shows the details of error codes.
3. Cautions on use
The error code is not cleared after the communication error is reset.
It is only cleared when the PLC mode is changed from STOP to RUN.
Device Error code Description Action
D8063
(ch 1)
0000 No error
Verify that the parallel link
setting programs are
correct, and check the wiring
also.
6312 Character error in parallel link
6313 Sum check error in parallel link
6314 Format error in parallel link
D8438
(ch 2)
0000 No error
3812 Character error in parallel link
3813 Sum check error in parallel link
3814 Format error in parallel link
