Mitsubishi FX3U-232-BD User Manual

H-19
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
3 Selecting Connection Cables
3.2 Connector Shape in Each Product
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
3.2 Connector Shape in Each Product
Model name (series) Connector shape
PLC
FX
1, FX2(FX) and FX2C
PLCs
FX
0, FX0S, FX0N, FX1S,
FX
1N, FX2N, FX3U, FX1NC,
FX
2NC and FX3UC PLCs
PLC (communication equipment)
FX
1N-422-BD
FX
2N-422-BD
FX
3U-422-BD
FX
0N-232ADP
FX
1N-232-BD
FX
2N-232-BD
FX
3U-232-BD
FX
2NC-232ADP
FX
3U-232ADP(-MB)
FX
3U-USB-BD
Handy programming panel
FX-10P(-E),
FX-10P-SET0(-E),
FX-20P(-E),
FX-20P-SET0(-E)
25-pin D-Sub,
female
13 1
25 14
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
25-pin D-Sub,
female
13 1
25 14
9-pin D-Sub,
male
5
1
96
5-pin MINI-USB
B plug, female
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
Personal computer
PC-AT compatible
machine
- DOS/V personal
computer
- Windows personal
computer
PC-9800 Series (NEC)
- Notebook type personal
computer
PC-9800 Series (NEC)
- Desktop type personal
computer
Model name (series) Connector shape
9-pin D-Sub,
male
5
1
96
14-pin Half-
pitch, female
14
7
1
8
25-pin D-Sub,
female
13 1
25 14

Mitsubishi FX3U-232-BD Specifications

General

Type	Communication Module
Model	FX3U-232-BD
Category	Controller
Communication Protocol	RS-232
Communication Standard	EIA-232
Number of Channels	1
Maximum Transmission Distance	15 meters
Data Bits	7 or 8 bits
Stop Bits	1 or 2 bits
Parity	None, Even, Odd
Power Supply	5V DC (from PLC)
Current Consumption	50 mA
Compatible PLC Series	FX3U, FX3UC
Baud Rate	300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
