E-112
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
12 Related Data
12.5 FREQROL Inverter Parameter List
12.5 FREQROL Inverter Parameter List
This section shows the list of parameters provided in FREQROL F700, A700, E700, V500, F500, A500, E500
and S500 Series inverters.
For details on each function, refer to the respective inverter manual.
12.5.1 Parameters in V500, F500, A500, E500, and S500 Series
The following parameters are provided in FREQROL inverters. (For details, make sure to refer to the
respective inverter manual.)
FREQROL V500 Series FREQROL F500 Series FREQROL A500 Series FREQROL E500 Series FREQROL S500 Series
Function
Pr
No.
Name
Pr
No.
Name
Pr
No.
Name
Pr
No.
Name
Pr
No.
Name
Basic
functions
0
Torque boost
(manual)
0 Torque boost 0
Torque boost
*3
0
Torque boost
*3
0
Torque boost
*3
1
Maximum speed
(simple mode)
1
Maximum
frequency
1
Maximum
frequency
1
Maximum
frequency
1
Maximum
frequency
2
Minimum speed
(simple mode)
2
Minimum
frequency
2
Minimum
frequency
2
Minimum
frequency
2
Minimum
frequency
3 Base frequency 3 Base frequency 3 Base frequency 3
Base frequency
*3
3
Base frequency
*3
4
Multi-speed
setting
(high speed)
(simple mode)
4
Multi-speed
setting
(high speed)
4
Multi-speed
setting
(high speed)
4
Multi-speed
setting
(high speed)
4
Multi-speed
setting
(high speed)
5
Multi-speed
setting
(middle speed)
(simple mode)
5
Multi-speed
setting
(middle speed)
5
Multi-speed
setting
(middle speed)
5
Multi-speed
setting
(middle speed)
5
Multi-speed
setting
(middle speed)
6
Multi-speed
setting
(low speed)
(simple mode)
6
Multi-speed
setting
(low speed)
6
Multi-speed
setting
(low speed)
6
Multi-speed
setting
(low speed)
6
Multi-speed
setting
(low speed)
7
Acceleration time
(simple mode)
7 Acceleration time 7 Acceleration time 7 Acceleration time 7 Acceleration time
8
Deceleration time
(simple mode)
8 Deceleration time 8 Deceleration time 8 Deceleration time 8 Deceleration time
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
Standard
operation
functions
10
DC injection brake
operation speed
10
DC injection brake
operation
frequency
10
DC injection brake
operation
frequency
10
DC injection brake
operation
frequency
10
DC injection brake
operation
frequency
11
DC injection brake
operation time
11
DC injection brake
operation time
11
DC injection brake
operation time
11
DC injection brake
operation time
11
DC injection brake
operation time
12
DC injection brake
voltage
12
DC injection brake
voltage
12
DC injection brake
voltage
12
DC injection brake
voltage
12
DC injection brake
voltage
13 Starting speed 13 Starting frequency 13 Starting frequency 13 Starting frequency 13 Starting frequency
⎯⎯14
Load pattern
selection
14
Load pattern
selection
*3
14
Load pattern
selection
*3
14
Load pattern
selection
*3
15 Jog speed setting 15 Jog frequency 15 Jog frequency 15 Jog frequency 15 Jog frequency
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
Standard
operation
function
(V500
Series
operation
selection
functions)
17
MRS input
selection
17
MRS input
selection
17
MRS input
selection
⎯⎯17
RUN key rotation
direction selection
⎯⎯⎯⎯18
High speed
maximum
frequency
18
High speed
maximum
frequency
⎯⎯
19
Base frequency
voltage
19
Base frequency
voltage
19
Base frequency
voltage
*3
19
Base frequency
voltage
*3
19
Base frequency
voltage
*3
