E-88
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
9 Creating Programs (for FX3U and FX3UC PLCs)
9.9 Second Parameter Specification Codes
9.9.8 E700 Series
1. Second parameter specification codes for parameter numbers 125, 126, C2 to C7 and C22 to
C25
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in IVRD/
IVWR instruction for parameter number]
C2 Terminal 2 frequency setting bias frequency 902
C3
Terminal 2 frequency setting bias 1902
Terminal 2 analog value 2902 (Only the IVRD instruction)
125 Terminal 2 frequency setting gain frequency 903
C4
Terminal 2 frequency setting gain 1903
Terminal 2 analog value 2903 (Only the IVRD instruction)
C5 Terminal 4 frequency setting bias frequency 904
C6
Terminal 4 frequency setting bias 1904
Terminal 4 analog value 2904 (Only the IVRD instruction)
126 Terminal 4 frequency setting gain frequency 905
C7
Terminal 4 frequency setting gain 1905
Terminal 4 analog value 2905 (Only the IVRD instruction)
C22
Frequency setting voltage bias frequency (built-in
potentiometer)
922
C23
Frequency setting voltage bias
(built-in potentiometer)
1922
C24
Frequency setting voltage gain frequency (built-in
potentiometer)
923
C25
Frequency setting voltage gain (built-in
potentiometer)
1923
S 2
