3.3.1 List of modems whose operations are confirmed
The tables below show already tested modems and their associated AT command.
1. Modem on the PLC side
The PLC has a command to initialize the PV-AF288 (manufactured by AIWA) and ME3314B (manufactured by
OMRON). This command can be used only by setting parameters using the GX Developer or FXGP/WIN
software.
For other modems, input and set the AT command shown below in ASCII code to a data register (D1000 and
later usually, and D200 or later in the FX1S PLC).
→ For the setting procedure, refer to Chapter 5.
2. Modem on the personal computer side for remote access
The table below shows modems whose operations are already confirmed. Input and set the AT command shown
below using a programming tool in the personal computer on the remote access side.
FXGP/WIN has a command to initialize the PV-AF288, PV-AF3360 (manufactured by AIWA), ME3314B, ME5614D
and ME5614E (manufactured by OMRON). This command can be used only by setting a parameter.
→ For the setting procedure, refer to Chapter 6.
*1. When used the FXGP/WIN, select the model "ME5614E".
Manufacturer
AT command setting for modem
on PLC side
AT command Remarks
Modem
model name
GX Developer
(SW
îš…
D5C-GPPW)
FX-PCS/WIN
Manufactured by I/O DATA
DFML-K56F
Input AT command shown on right
ATE0Q1S0=2&D0&K0&W0&Y0\Q0%C3
Manufactured by AIWA
PV-AF288
Select AIWA modem (PV-AF288)
ATE0S0=2Q1&D0&M5\Q0\J0&W
PV-BF5606
Input AT command shown on right
ATE0S0=2&D0Q1&K0&W
Manufactured by OMRON
ME3314B
Select OMRON modem (ME3314B)
ATE0S0=2Q1&D0&H0&R1S15=8&W
In FX
2N
PLCs, Ver. 2.01 and
later are applicable.
ME5614E
Input AT command shown on right
ATE0S0=2&D0Q1&K0&W
Modem version: F/W Ver. 2.300
ME5614E2
ME5614D
Input AT command shown on right
ATE0S0=2&D0Q1&K0&W Modem version: F/W Ver. 2.300
Manufactured by NTT DoCoMo
96F1
Input AT command shown on right
ATE0S0=2&D0\Q1
96F2
Input AT command shown on right
ATE0S0=2&D0\Q1Q1
Manufacturer AT command setting for modem on personal computer side for remote access
Remarks
Modem
model name
GX Developer
(SW
îš…
D5C-GPPW)
FX-PCS/WIN
Manufactured by AIWA
PV-AF288
—
Select this model (AT command is shown for reference)
ATE0S0=2Q0V1&M4\J0\Q0
PV-AF3360
—
Select this model (AT command is shown for reference)
ATE0S0=2Q0V1S15=8&H0&R1
PV-BF5606 ATE0S0=2&K0&D0
Select this model (AT command is shown for reference)
ATE0S0=2&K0
Manufactured by OMRON
ME3314B
—
Select this model (AT command is shown for reference)
ATE0S0=2Q0V1S15=8&H0&R1
ME5614E
ATE0S0=2&K0&D0
Select this model (AT command is shown for reference)
ATE0S0=2&K0W0
Modem version: F/W
Ver. 2.300
ME5614E2
*1
ME5614D ATE0S0=2&K0&D0
Select this model (AT command is shown for reference)
ATE0S0=2&K0W0
Modem version: F/W
Ver. 2.300
Manufactured by NTT DoCoMo
96F1 ATQ0V1E1S0=0 ATQ0V1E1S0=0
SW
îš…
D5C-GPPW
version: before SW3
96F2
ATQ0V1E1
ATQ0V1E1
SW
îš…
D5C-GPPW
version: before SW3
ATQ0V1E1\Q1
SW
îš…
D5C-GPPW
version: SW4 or later
To Next Page
