Inverter Communication
9 Creating Programs (for FX3U and FX3UC PLCs)
9.9 Second Parameter Specification Codes
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
9.9.3 A500 Series
1. Second parameter specification codes for parameter numbers 201 to 230 and 902 to 905
2. Second parameter specification codes for parameter numbers 902 to 905
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in IVRD/IVWR
instruction for parameter number]
Operation frequency
read/write
Time read/write
Rotation direction
write/read
201 Program set 1 201 1201 2201
202 Program set 1 202 1202 2202
203 Program set 1 203 1203 2203
204 Program set 1 204 1204 2204
205 Program set 1 205 1205 2205
206 Program set 1 206 1206 2206
207 Program set 1 207 1207 2207
208 Program set 1 208 1208 2208
209 Program set 1 209 1209 2209
210 Program set 1 210 1210 2210
211 Program set 2 211 1211 2211
212 Program set 2 212 1212 2212
213 Program set 2 213 1213 2213
214 Program set 2 214 1214 2214
215 Program set 2 215 1215 2215
216 Program set 2 216 1216 2216
217 Program set 2 217 1217 2217
218 Program set 2 218 1218 2218
219 Program set 2 219 1219 2219
220 Program set 2 220 1220 2220
221 Program set 3 221 1221 2221
222 Program set 3 222 1222 2222
223 Program set 3 223 1223 2223
224 Program set 3 224 1224 2224
225 Program set 3 225 1225 2225
226 Program set 3 226 1226 2226
227 Program set 3 227 1227 2227
228 Program set 3 228 1228 2228
229 Program set 3 229 1229 2229
230 Program set 3 230 1230 2230
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in IVRD/IVWR
instruction for parameter number]
Offset/Gain
(H00)
Analog
(H01)
Analog value of
terminal (H02)
902 Frequency setting voltage bias 902 1902 2902
903 Frequency setting voltage gain 903 1903 2903
904 Frequency setting current bias 904 1904 2904
905 Frequency setting current gain 905 1905 2905
