Terminal 2 frequency setting
gain frequency
125
Terminal 2 frequency setting
gain frequency
125
Terminal 2 frequency setting
gain frequency
− 126
Terminal 4 frequency setting
gain frequency
126
Terminal 4 frequency setting
gain frequency
126
Terminal 4 frequency setting
gain frequency
PID operation
127
PID control automatic switchover
frequency
127
PID control automatic switchover
frequency
127
PID control automatic switchover
frequency
128 PID action selection 128 PID action selection 128 PID action selection
129 PID proportional band 129 PID proportional band 129 PID proportional band
130 PID integral time 130 PID integral time 130 PID integral time
131 PID maximum 131 PID upper limit 131 PID upper limit
132 PID minimum 132 PID lower limit 132 PID lower limit
133 PID action set point 133 PID action set point 133 PID action set point
134 PID differential time 134 PID differential time 134 PID differential time
Commercial
power
supply-
inverter
switch-over
135
Commercial power−supply
switchover sequence output
terminal selection
135
Electronic bypass sequence
selection
−−
136 MC switchover interlock time 136 MC switchover interlock time
137 Waiting time at a start 137 Start waiting time
138
Commercial power-supply
operation switchover selection at
an alarm
138 Bypass selection at an alarm
139
Automatic switchover frequency
between inverter and
commercial power-supply
operation
139
Automatic switchover frequency
from inverter to bypass operation
Backlash
measures
140
Backlash acceleration stopping
frequency
140
Backlash acceleration stopping
frequency
141
Backlash acceleration stopping
time
141
Backlash acceleration stopping
time
142
Backlash deceleration stopping
frequency
142
Backlash deceleration stopping
frequency
143
Backlash deceleration stopping
time
143
Backlash deceleration stopping
time
− 144 Speed setting switchover 144 Speed setting switchover
PU 145 PU display language selection 145 PU display language selection 145 PU display language selection
−− − − - 146 Built-in potentiometer switching
Current
detection
148 Stall prevention level at 0V input. 148 Stall prevention level at 0V input
−−
149
Stall prevention level at 10V
input.
149
Stall prevention level at 10V
input
150 Output current detection level 150 Output current detection level 150 Output current detection level
151
Output current detection signal
delay time
151
Output current detection signal
delay time
151
Output current detection signal
delay time
152 Zero current detection level 152 Zero current detection level 152 Zero current detection level
153 Zero current detection time 153 Zero current detection time 153 Zero current detection time
− 154
Voltage reduction selection
during stall prevention operation
154
Voltage reduction selection
during stall prevention operation
−−
− 155
RT signal reflection time
selection
155
RT signal function validity
condition selection
− 156
Stall prevention operation
selection
156
Stall prevention operation
selection
156
Stall prevention operation
selection
− 157 OL signal output timer 157 OL signal output timer 157 OL signal output timer
− 158 AM terminal function selection 158 AM terminal function selection
−−
− 159
Automatic switchover ON range
between commercial power−
supply and inverter operation
159
Automatic switchover frequency
range from bypass to inverter
operation
− 160 User group read selection 160 User group read selection 160 User group read selection
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
