Mitsubishi FX3U-232-BD User Manual

B-14
FX Series PLC User's Manual - Data Communication Edition
N:N Network
3 System Configuration and Equipment Selection
3.2 Applicable FX PLC and Communication Equipment
FX3U
When using channel 1 (ch 1)
50 m
(164' 0")
500 m
(1640' 5")
When using channel 2 (ch 2)
500 m
(1640' 5")
500 m
(1640' 5")
FX
1NC
500 m
(1640' 5")
FX
2NC
500 m
(1640' 5")
FX Series Communication equipment (option)
Total extension
distance
Check
ch1
FX
3U -485-BD
(European terminal block)
RD
RD A
RD B
SD A
SD B
SG
SD
FX 3U -CNV-BD
+
FX 3U -485ADP(-MB)
(European terminal block)
ch1
+
FX 3U -485ADP(-MB)
(European terminal block)
ch2
FX
3U -  -BD
(Where  represents
232, 422, 485, and USB).
ch1
RD
SD
FX 3U -CNV-BD
+
FX 3U -  ADP(-MB)
(Where  represents
232 and 485).
ch1
+
FX 3U -485ADP(-MB)
(European terminal block)
ch2
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)
FX 2NC -485ADP
(European terminal block)
FX 0N -485ADP
(Terminal block)

Mitsubishi FX3U-232-BD Specifications

General

Brand	Mitsubishi
Model	FX3U-232-BD
Category	Controller
Language	English
