D-18
FX Series PLC User's Manual - Data Communication Edition
Computer Link
3 System Configuration and Equipment Selection
3.2 Applicable FX PLC and Communication Equipment
FX Series Communication equipment (option)
Total extension
distance
Check
FX
2(FX)
15 m
(49' 2")
FX
2C
15 m
(49' 2")
FX-232ADP
(25-pin D-Sub, female)
FX-232ADP
(25-pin D-Sub, female)
