E-40
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
5 Communication Setting in Inverter
5.6 E700 Series (when PU port is connected)
3. Others (which should be set if necessary)
The table below shows parameters to be considered when using various system configuration and inverters.
For the method of use, refer to the respective inverter manual.
*1. Pr37 cannot be set using this inverter communication function.
*2. Set Pr146 to "1" when changing the frequency from the PLC.
Parameter No. Parameter item Set value Setting contents
Pr37
Speed display
*1
0 or 0.01
to 9998
0: Frequency display, setting
0.01 to 9998: Machine speed at 60Hz.
Pr146
Built-in potentiometer switching
*2
0 or 1
0: Built-in frequency setting potentiometer
valid
1: Built-in frequency setting potentiometer
invalid
Pr342 Communication EEPROM write selection 0 or 1
0: EEPROM is written.
1: RAM is written.
To Next Page
