FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
8 Practical Program Examples (for FX2N and FX2NC PLCs)
8.1 Practical Example 1
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
3. Controlling operations of an inverter
X000
SET M15
Operation stop
command input
Operation
stop
Operation stop is reset
by input X001 or X002
b1 of H0FA is set to ON
H0FA is set to "00H"
RST M15
Operation
stop
Forward rotation
command
Forward
rotation
command
input
b2 of H0FA is set to ON
Operation command is written
M27 to M20
→ H0FA
X002
X001
X002
Reverse rotation
command input
X000
Operation stop
command input
M21
M15
Operation
stop
X001 X002
X001
Forward
rotation
command
input
Reverse rotation
command input
Reverse
rotation
command
input
Forward rotation
command input
M8000
RUN monitor
M22
Reverse rotation
command
H0FA K2M20
FNC180
EXTR
K11 K0
