I-43
FX Series PLC User's Manual - Data Communication Edition
Remote Maintenance
7 Connecting Line
7.2 Line Connection Procedure
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter
Communication
F
Non-Protocol
Communication
(RS/RS2 Instruction)
G
Non-Protocol
Communication
(FX
2N
-232IF)
H
Programming
Communication
I
Remote
Maintenance
Apx.
Discontinued
models
11 Disconnecting the line
To disconnect the line, select [Tools] - [Set TEL data] - [Disconnection] from the toolbar.
When the following dialog box appears, click the [Yes] button to disconnect the line.
When line disconnection is finished, the following dialog box appears to indicate the connection
destination telephone number and line use time.
Click the [OK] button to close the dialog box.
To Next Page
