Program 68
This program assigns various features of FAX/DUD (Optional Item for TX-Z 308 system).
Display Indication Input Data Initial
FAX ASSIGNMENT2
68 –ABCDE
A. Line assignment
0: FAX 1: DUD 2: FAX & DUD
B. When CNG signal is not detected
0: Cut-off 1: Transfer to Operator (No.10)
2: Transfer to FAX port
C. When extension is busy
0: Cut-off 1: Transfer to Operator (No.10)
2: Re-send Attendant Message No. 2
D. --Not Used --
E. --Not Used --
A: 0
B: 2
C: 0
D: 0
E: 0
Program 69
This program defines each timer for FAX feature. (Optional Item for TX-308 System.)
Display Indication Input Data Initial
FAX ASSIGNMENT3
# ## 69-N –TTT
N. Timer Assignment
1: Automatic Answer time
2: CNG signal waiting time
3: Waiting time for DTMF signal
4: SLT/FAX calling time
TTT. Time
000 = Immediate answer (N = 1)
000 = Not assigned (N = 2 - 4)
001 - 255 = 1 - 255 seconds (N = 1 - 4)
<N = 1>
TTT: 000
<N = 2>
TTT: 015
<N = 3>
TTT: 010
<N = 4>
TTT: 030
TX-Z 308 Only
TX-Z 308 Only
