2.4.3.36 Port P Data Direction Register (DDRP)
2.4.3.37 Port P Pull Device Enable Register (PERP)
Address 0x025A (G1, G2) Access: User read/write
1
1
Read: Anytime
Write: Anytime
76543210
R
DDRP7 DDRP6 DDRP5 DDRP4 DDRP3 DDRP2 DDRP1 DDRP0
W
Reset00000000
Address 0x025A (G3) Access: User read/write
1
76543210
R0 0
DDRP5 DDRP4 DDRP3 DDRP2 DDRP1 DDRP0
W
Reset00000000
Figure 2-37. Port P Data Direction Register (DDRP)
Table 2-63. DDRP Register Field Descriptions
Field Description
7-0
DDRP
Port P data direction—
This bit determines whether the associated pin is an input or output.
1 Associated pin configured as output
0 Associated pin configured as input
Address 0x025C (G1, G2) Access: User read/write
1
1
Read: Anytime
Write: Anytime
76543210
R
PERP7 PERP6 PERP5 PERP4 PERP3 PERP2 PERP1 PERP0
W
Reset00000000
Address 0x025C (G3) Access: User read/write
1
76543210
R0 0
PERP5 PERP4 PERP3 PERP2 PERP1 PERP0
W
Reset00000000
Figure 2-38. Port P Pull Device Enable Register (PERP)
