Port Integration Module (S12GPIMV1)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 231
2.4.3.49 Port AD Data Register (PT0AD)
2.4.3.50 Port AD Data Register (PT1AD)
Address 0x0270 (G1, G2) Access: User read/write
1
1
Read: Anytime. The data source is depending on the data direction value.
Write: Anytime
76543210
R
PT0AD7 PT0AD6 PT0AD5 PT0AD4 PT0AD3 PT0AD2 PT0AD1 PT0AD0
W
Reset00000000
Address 0x0270 (G3) Access: User read/write
1
76543210
R0000
PT0AD3 PT0AD2 PT0AD1 PT0AD0
W
Reset00000000
Figure 2-49. Port AD Data Register (PT0AD)
Table 2-75. PT0AD Register Field Descriptions
Field Description
7-0
PT0AD
Port AD general-purpose input/output data—Data Register
When not used with an alternative signal, the associated pin can be used as general-purpose I/O. In general-purpose
output mode the port data register bit value is driven to the pin.
If the associated data direction bit is set to 1, a read returns the value of the port data register bit, otherwise the
buffered pin input state is read if the digital input buffers are enabled (Section 2.3.12, “Pins AD15-0”).
Address 0x0271 Access: User read/write
1
1
Read: Anytime. The data source is depending on the data direction value.
Write: Anytime
76543210
R
PT1AD7 PT1AD6 PT1AD5 PT1AD4 PT1AD3 PT1AD2 PT1AD1 PT1AD0
W
Reset00000000
Figure 2-50. Port AD Data Register (PT1AD)
