Serial Peripheral Interface (S12SPIV5)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 699
0 0 1 0 1 0 16 1.5625 Mbit/s
0 0 1 0 1 1 32 781.25 kbit/s
0 0 1 1 0 0 64 390.63 kbit/s
0 0 1 1 0 1 128 195.31 kbit/s
0 0 1 1 1 0 256 97.66 kbit/s
0 0 1 1 1 1 512 48.83 kbit/s
0 1 0 0 0 0 6 4.16667 Mbit/s
0 1 0 0 0 1 12 2.08333 Mbit/s
0 1 0 0 1 0 24 1.04167 Mbit/s
0 1 0 0 1 1 48 520.83 kbit/s
0 1 0 1 0 0 96 260.42 kbit/s
0 1 0 1 0 1 192 130.21 kbit/s
0 1 0 1 1 0 384 65.10 kbit/s
0 1 0 1 1 1 768 32.55 kbit/s
0 1 1 0 0 0 8 3.125 Mbit/s
0 1 1 0 0 1 16 1.5625 Mbit/s
0 1 1 0 1 0 32 781.25 kbit/s
0 1 1 0 1 1 64 390.63 kbit/s
0 1 1 1 0 0 128 195.31 kbit/s
0 1 1 1 0 1 256 97.66 kbit/s
0 1 1 1 1 0 512 48.83 kbit/s
0 1 1 1 1 1 1024 24.41 kbit/s
1 0 0 0 0 0 10 2.5 Mbit/s
1 0 0 0 0 1 20 1.25 Mbit/s
1 0 0 0 1 0 40 625 kbit/s
1 0 0 0 1 1 80 312.5 kbit/s
1 0 0 1 0 0 160 156.25 kbit/s
1 0 0 1 0 1 320 78.13 kbit/s
1 0 0 1 1 0 640 39.06 kbit/s
1 0 0 1 1 1 1280 19.53 kbit/s
1 0 1 0 0 0 12 2.08333 Mbit/s
1 0 1 0 0 1 24 1.04167 Mbit/s
1 0 1 0 1 0 48 520.83 kbit/s
1 0 1 0 1 1 96 260.42 kbit/s
1 0 1 1 0 0 192 130.21 kbit/s
1 0 1 1 0 1 384 65.10 kbit/s
1 0 1 1 1 0 768 32.55 kbit/s
1 0 1 1 1 1 1536 16.28 kbit/s
1 1 0 0 0 0 14 1.78571 Mbit/s
Table 21-6. Example SPI Baud Rate Selection (25 MHz Bus Clock)
SPPR2 SPPR1 SPPR0 SPR2 SPR1 SPR0
Baud Rate
Divisor
Baud Rate
