Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 218 of 765
Mar 7, 2023
(b) When operation starts with slave channel output mode (TOMmp = 1) setting (PWM output))
When slave channel output mode (TOMmp = 1), the active level is determined by timer output level register m (TOLm)
setting.
Figure 6-32. TOmp Pin Output Status at PWM Output (TOMmp = 1)
Hi - Z
Default
status
TOEmp
Port
output is
enabled
Set Reset Set
Reset Set
TOmp bit =
0
(
Default status:
Low
)
TOmp bit = 1
(
Default status: High)
TOmp bit = 0
(
Default status:
Low)
TOmp bit = 1
(Default status:
High)
TOmp
(Output)
TOLmp bit
=
0
(Active high)
TOLmp bit
= 1
(Active low)
Active Active Active
Remark 1. Set: The output signal of the TOmp pin changes from inactive level to active level.
Reset: The output signal of the TOmp pin changes from active level to inactive level.
Remark 2. m: Unit number (m = 0), p: Channel number (p = 1 to 7)
