RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 294 of 765

Mar 7, 2023

Figure 6-81. Example of Set Contents of Registers for Two-channel Input with One-shot Pulse Output Function

(Master Channel) (2/2)

(b) Timer output register 0 (TO0)

Bit n

TO0 TO0n 0: Outputs 0 from TO0n.

Bit n

TOE0 TOE0n

0: Stops the TO0n output operation by counting operation.

(d) Timer output level register 0 (TOL0)

Bit n

TOL0 TOL0n

0: Setting is invalid because master channel output mode is set (TOM0n = 0).

(e) Timer output mode register 0 (TOM0)

Bit n

TOM0

TOM0n

0: Sets master channel output mode.

Remark n: Master channel number (n = 0, 2)
