RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 493 of 765

Mar 7, 2023

Note 1. The SMR01 register only.

Note 2. The SCR00 register only.

Note 3. Because the setting is completed by address field transmission, setting is not required.

Note 4. The value varies depending on the communication data during communication operation.

Remark 1. m: Unit number (m = 0), n: Channel number (n = 0, 1), r: IIC number (r = 00, 01), mn = 00, 01

Remark 2.

: Setting is fixed in the IIC mode, : Setting disabled (set to the initial value)

0/1: Set to 0 or 1 depending on the usage of the user.
