RL78/G15 CHAPTER 3 CPU ARCHITECTURE

R01UH0959EJ0110 Rev.1.10 Page 58 of 765

Mar 7, 2023

Remark The flash memory is divided into blocks (one block = 1 KB). For the address values and block numbers, see

Table 3-1. Correspondence Between Address Values and Block Numbers in Flash Memory.

Block 00H

Block

Block 07H

00000H

00400H

003FFH

FFFH

007

FFH

01C00H

01BFFH

1 KB

120

(

x =

, 4

, 6

))

Table 3-1. Correspondence Between Address Values and Block Numbers in Flash Memory

Address Value Block Number

00000H to 003FFH 00H

00400H to 007FFH 01H

00800H to 00BFFH 02H

00C00H to 00FFFH 03H

01000H to 013FFH 04H

01400H to 017FFH 05H

01800H to 01BFFH 06H

01C00H to 01FFFH 07H
